Maxi-Ject Pro

Description	V-12 Injector
Use	Light-Medium Duty
Rebuildable	Yes
Max. Hydraulic (+) PSI	120
Max. Air (+) PSI	80
Max. Vacuum (-)" HG	-20
Injection Stroke	10 ml
Adjustable Dosage	Yes
Hi-Fluid Viscosities (thick)	No
Hand Force (1=Easiest)	3
Adjustable Return Force	No
Handle	Pivot
Standard Color	Black
Feature Rating (10=Highest)	7

Features

Zytel body

10 ml/injection stroke

High hydraulic advantage

Light-Medium Duty

Re-buildable

Inexpensive

Clutch/Brake Applications

Full Modular Capabilities

Adjustable injection stroke

Ergonomic design

Description

The V-12 Injector is designed to inexpensively perform RFI, vacuum/pressure bleeding and master cylinder bench bleeding. The small piston diameter provides high hydraulic advantage. The V-12 can develop 120 PSI. with comfortable hand force. The function of the V-12 Injector is identical to our other more expensive RFI Injectors. When the injector handle is depressed fluid is injected through the nozzle. When the handle is released, the Injector automatically refills the barrel from a remote fluid source. The modular design of the V-12 allows the injector to be easily utilized for vacuum, pressure and RFI bleeding. The handle and body are made of high strength Zytel (glass reinforced nylon) which imparts metal like strength while retaining light weight comfort and control. The V-12 ergonomic design is very compact and comfortable to use.
